Ổ cứng Seagate Enterprise Capacity 8TB SAS 3.5 ST8000NM0075
Ổ cứng Seagate Enterprise Capacity 8TB SAS 3.5 ST8000NM0075
Specifications SATA 6Gb/s 12Gb/s SAS
8TB1, 2 8TB1, 2
Standard Model Number (4K Native) ST8000NM0045 ST8000NM0065
Standard Model Number (512 Emulation) ST8000NM0055 ST8000NM0075
SED Model Number (4K Native) ST8000NM01153 ST8000NM00953
SED Model Number (512 Emulation) ST8000NM01053 ST8000NM00853
Features
Protection Information (T10 DIF) — Yes
Humidity Sensor Yes Yes
Super Parity Yes Yes
Low Halogen Yes Yes
PowerChoice™ Technology Yes Yes
PowerBalance™ Technology Yes Yes
Cache, Multisegmented (MB) 256 256
Advanced Write Caching (2M Internal NOR Flash) Yes Yes
Reliability/Data Integrity
Mean Time Between Failures (MTBF, hours) 2.0M 2.0M
Reliability Rating @ Full 24×7 Operation (AFR) 0.44% 0.44%
Nonrecoverable Read Errors per Bits Read 1 sector per 10E15 1 sector per 10E15
Power-On Hours per Year 8760 (24×7) 8760 (24×7)
Sector Size (Bytes per Logical Sector) 512 and 4096 512, 520, 528, 4096, 4160 and 4224
Limited Warranty (years) 5 5
Performance
Spindle Speed (RPM) 7200 7200
Interface Access Speed (Gb/s) 6.0, 3.0, 1.5 12.0, 6.0, 3.0
Max IOPS Efficiency, Random Writes (IOPS/W) 36 36
Random Read/Write—16QD WCE (IOPS) 165/380 165/380
Max. Sustained Transfer Rate OD (MB/s) up to 237 up to 237
Average Latency (ms) 4.16 4.16
Interface Ports Single Dual
Rotational Vibration @ 1500 Hz (rad/s²) 12.5 12.5
Power Consumption
Idle A Power, Average (W) 7.5 8.0
Max Operating, Random Read 4KQ16 (W) 10.4 11.4
PowerBalance Max Operating, Random Read 4KQ16 (W) 8.8 8.8
Power Supply Requirements +12V and +5V +12V and +5V
Environmental
Temperature, Operating (°C) 5 to 60 5 to 60
Vibration, Nonoperating: 10Hz to 500Hz (Grms) 5.0 4.9
Shock, Operating, 2ms (Read/Write) (Gs) 70/40 70/40
Shock, Nonoperating, 1ms and 2ms (Gs) 250 250
Physical
Height (in/mm, max)4 1.028/26.1 1.028/26.1
Width (in/mm, max)4 4.010/101.85 4.010/101.85
Depth (in/mm, max)4 5.787/147.0 5.787/147.0
Weight (lb/g) 1.720/780 1.720/780
Carton Unit Quantity 20 20
Cartons per Pallet 40 40
Cartons per Layer 8 8
